The Moxon Rectangle: A Comprehensive Guide
A comprehensive guide to building and using the Moxon Rectangle antenna for HF operation.
Description
Presents the construction and performance characteristics of the Moxon Rectangle antenna, a compact, directional HF antenna design. It details the antenna's physical structure, emphasizing its robust build and ease of erection compared to traditional Yagis. The resource provides specific dimensions for building Moxons for the 10m through 40m bands, derived from W4RNL's work, and discusses the critical element spacing for optimal performance. It also covers feeding the antenna with a simple choke balun and achieving a low SWR across the band.
Compares the Moxon's performance to a two-element Yagi, noting its superior wind resistance and compact footprint. The author, VK3BCY, shares personal experiences with a 20m Moxon, reporting SWRs below 1.3 across the entire band and strong signal reports from DX stations with only 100 Watts. EZNEC Pro modeling data is included to illustrate gain and front-to-back ratios, confirming the antenna's high-performance claims. The article also briefly explores multi-band possibilities and reversible configurations.
