QRP Frequencies

QRP Frequencies on HF VHF Ham Radio Bands

1426

QRP in ham radio Q-code means “Lower Output Power” and commonly denotes an operating mode that implements reduced output power, commonly understood as 5W, although sometimes even lower levels such as 1W can be achieved.

QRP mode is often used by hams operating in portable mode, where alternative power sources that do not allow for higher output power are often used, also in order to ensure a longer period of operation.

On the amateur radio bands, there are dedicated calling frequencies, also named Centers of Activity, for those operating in QRP mode.

BandCW Frequencies MHzPhone Frequencies MHz
160m1.810
1.836 (IARU R1)
1.815 (VK)
1.843
1.910 (LSB)
80m3.560 (IARU R1)
3.530 (VK)
3.710 (Novice)
3.985
3.690 (IARU R1)
60m5.262 (UK)5.346,5 (Ch2)
40m7.030 (IARU R1)
7.040
7.060
7.122
7.028 (VK)
7.110 (Novice)
7.285 (LSB)
7.090 (IARU R1)
7.060
30m10.106
10.116
10.140
20m14.06014.285
17m18.09618.130
15m21.060
21.110 (Novice)
21.385
21.285 (IARU R1)
12m24.90624.950
10m28.060
28.110 (Novice)
28.385
28.360 (IARU R1)
28.885
6m50.096
50.060 (IARU R1)
50.185
50.285 (SSB IARU R1)
50.885
2m144.060144.285 (SSB IARU R1)
14.585 (FM)
QRP Calling Frequencies

Notes:

The default frequencies refers to all IARU Regiones otherwise exceptions are indicated behind the frequency.

Phone frequencies are by default SSB.

IARU
Region 1 (Europe, Africa, Middle East and Northern Asia)
Region 2 Americas
Region 3 Asia-Pacific

Sources:

About QRP

One of the reasons QRP operation is so popular and attractive is that low power transmission equipment is usually very light and inexpensive.

QRP kits are very popular among hams. Basically QRP Kits are simple transceivers that allow you to go on the air with a very limited power supply. Many QRP Clubs produce and support the development of these kits. Usually the antennas for this type of activity are wire antennas, usually very simple and easily transportable.

QRP activities are obviously much more difficult and unpredictable, making this operating technique a very fascinating and challenging method of communication.

If you want to contribute to this article, make corrections or just need to discuss about QRP Frequencies, just leave a comment here below.
